Rega Elex MK4 Integrated Amplifier

Name: Rega Elex MK4 Integrated Amplifier
Brand: Rega
SKU: AMP-ELEX-MK4-USA
Price: 2699.00 CAD
Availability: InStock

$2,699.00 CAD

The Rega Elex MK4 is a Class A/B integrated amplifier delivering 72 watts per channel into 8 ohms and 90 watts into 6 ohms. It combines four line-level inputs with a moving-magnet phono stage, a headphone output and a Rega DAC circuit for optical and coaxial digital sources.

Digital and analogue power rails are galvanically isolated, and the DAC uses a Wolfson receiver and converter with a Rega-designed discrete line driver. The custom case acts as an efficient heat sink, while thermal, short-circuit and DC protection are built in.

Specifications

Power output: 72 W per channel into 8 ohms; 90 W per channel into 6 ohms
Frequency response (line inputs): 10 Hz (−1 dB) to 65 kHz (−3 dB)
THD+N (line input to amplifier output): typically 0.005% at 1 kHz, A-weighted; measured 1 dB below clipping into 8 ohms, 22 Hz–22 kHz measurement bandwidth
Signal path gain (power amplifier): 31.6 dB
Amplifier type: Class A/B stereo integrated
Analogue inputs: 4 line-level; moving-magnet phono
Digital inputs: 1 optical; 1 coaxial
Digital support: 16-24 bit; 32-192 kHz
Output: Headphone
Protection: Thermal cut-out; short-circuit; DC
Power consumption: 250 W
Dimensions (W x H x D): 432 x 82 x 340 mm, including speaker terminals
Weight: 11 kg
